The refined engagement mechanism ensures stable connection, smooth response, and dependable power transmission for road cycling applications.
The straight-pull Center Lock design combined with AL6061-T6 and AL7075 alloy components provides reliable stiffness and performance for modern road disc wheel systems.
| # |
Type
|
Details
|
|---|---|---|
1 |
Hub Shell Material
|
AL6061-T6 aluminum alloy（100% Forging）
|
2 |
Axle Material
|
AL7075 aluminum alloy（100% Forging）
|
3 |
Freehub Body Material
|
AL7075 aluminum alloy（100% Forging）
|
4 |
End Cap Material
|
AL7075 aluminum alloy（100% Forging）
|
5 |
Disc Brake Interface
|
Road Center Lock Disc Brake Straight-Pull Hub
|
6 |
Hole Count
|
F-24H/R-24H
|
7 |
Hole Diameter
|
14G
|
8 |
Surface Color
|
Sandblasted anodized black
|
9 |
Freehub Body Color
|
Anodized Black
|
10 |
Bearing Configuration
|
S&S steel bearings (standard), ENDURO, CeramicSpeed
|
11 |
Hub Structure
|
4 pawls single-tooth
|
12 |
Freehub Body Standard
|
Shimano HG/Shimano Microspline(MS)-Road/SRAM XDR/Campagnolo Next 3/Campagnolo 11/12S
|
13 |
O.L.D.
|
F-12*100MM、R-12*142MM
|
14 |
Weight
|
363g±5g
|
Built with lightweight aluminum components for modern road disc wheel builds.
✓ High-Strength Aerospace-Grade 7075 Aluminum Alloy Axle & Freehub Body
Axle, end caps, and freehub body provide reliable stiffness and durability.
✓ 4-Pawl, Single-Tooth System
Delivers 48-point engagement and consistent power transfer.
✓ Multiple Freehub Options
Compatible with HG, MSR, XDR, N3W, and CP.
✓ Road Thru-Axle Platform
Features 12×100mm front and 12×142mm rear spacing.
✓ Center Lock Straight-Pull Design
24H front and rear, 14G spokes, S&S steel bearings, and a total weight of 363g.
